95. “Morphological transitions from dendrites to nanowires in the electroless deposition of silver”
A. V. Avizienis, C. Martin-Olmos, H. O. Sillin, M. Aono, J. K. Gimzewski,
and Adam Z. Stieg
Crystal Growth Design 13 (2013) 465–469.
DOI: 10.1021/cg301692n
96. “A theoretical and experimental study of neuromorphic atomic switch networks
for reservoir computing”
H. O. Sillin, R. Aguilera, H. H. Shieh, A. V. Avizienis, M. Aono, A. Z. Stieg,
and J. K. Gimzewski
Nanotechnology 24 (2013) 384004.
DOI: 10.1088/0957-4484/24/38/384004
2014
97. “Two types of on-sate observed in the operation of redox-based three-terminal
device”
Q. Wang, Y. Itoh, T. Tsuruoka, T. Hasegawa, S. Watanabe, S. Yamaguchi,
and M. Aono
Key Engineering Material 596 (2014) 111–115.
DOI: 10.4028/www.scientific.net/KEM.596.111
98. “Influence of atmosphere on photo-assisted atomic switch operations”
T. Hino, T. Hasegawa, H. Tanaka, T. Tsuruoka, T. Ogawa, and M. Aono
Key Engineering Material 596 (2014) 116–120.
DOI: 10.4028/www.scientific.net/KEM.596.116
99. “Impact of overshoot current on set operation of atom switch”
T. Sakamoto, M. Tada, M. Miyamura, N. Banno, K. Okamoto, N. Iguchi,
and H. Hada
Japanese Journal of Applied Physics 53 (2014) 04ED07.
DOI: 10.7567/JJAP.53.04ED07
100. “Low-power programmable-logic cell arrays using nonvolatile complementary
atom switch”
M. Miyamura, T. Sakamoto, M. Tada, N. Banno, K. Okamoto, N. Iguchi,
and H. Hada
Fifteenth International Symposium on Quality Electronic Design 2014,
330–334.
DOI: 10.1109/ISQED.2014.6783344
101. “A fast and low-voltage Cu complementary-atom-switch 1Mb array with hightemperature retention”
N. Banno, M. Tada, T. Sakamoto, M. Miyamura, K. Okamoto, N. Iguchi,
and H. Hada
2014 Symposium on VLSI Technology, 1–2.
DOI: 10.1109/VLSIT.2014.6894437
A List of Papers Related to the Atomic Switch
257
