210
A. Nogales et al.
during secondary crystallization the segmental immobilization induced by the crystalline phase is not as effective as in the previous period. As a matter of fact, in this
period the amount of immobilized material runs in parallel to the amount of material
incorporated to the crystals.
5 Polymer Crystallization Induced by Strain: The Case
of Vulcanized Natural Rubber
Although temperature is the main variable involved in most of the studies in polymer
crystallization also other magnitudes like pressure [58], shear [59] and strain [60]
can play an important role in the crystallization process. A paradigmatic case for
strain induced polymer crystallization is the one occurring in rubbers [61]. Natural
rubber (NR) is a natural amorphous polymer (T g ≈ −64
° C) basically consisting of
cis-1,4-isoprene units. NR is one of the most important natural materials present in
many products of our everyday life. It possesses a unique microstructure consisting
of different type of chain connections leading to the formations of a naturally occurring network formed by branch, star and network structures [62]. For most of the
NR industrial applications it is compulsory to enhance both elasticity and tensile
strength by converting the weak naturally occurring network into a more robust threedimensional network [63]. This can be achieved by a process known as vulcanization
by which cross-linking of the polymer chains is produced by covalent bonding formation typically by chemical reaction with sulfur [64]. As far as BDS is concern NR
exhibits above its glass transition temperature two dielectric relaxation processes
which are illustrated in Fig. 11a for a NR sample (Malaysian Rubber: Berhad,
Malaysia, SMR CV60). Similarly to synthetic 1,4-cis-poly(isoprene) (PI) [65, 66],
NR presents an asymmetry in its chemical structure inducing components of the
dipolar moment parallel and perpendicular to the polymer chain. For this reason
NR exhibits a standard segmental relaxation process, associated to the perpendicular
dipole moment, and an additional slower one, referred to as normal mode, associated
to the parallel dipole moment [65].
For vulcanized NR the dielectric relaxation process associated to the normal mode
is suppressed as a consequence of the crosslinking (Fig. 11b). Therefore vulcanized
NR exhibits above T g only the α-relaxation associated to the segmental motions of
the polymer chains [64, 67].
Natural rubber, similarly to other polymers, can crystallize by thermal treatment
within the temperature window defined by its T g and its melting point [68]. However
the crystallization rate is rather slow reaching a maximum at T c ≈ −20
° C [69]. It
has been proposed that the mechanical performance of vulcanized NR originates
from partial crystallization under the action of an extensional field. The formation
of strain-induced crystals can be responsible of the tensile modulus enhancement
observed when NR is subjected to fast deformations. The crystals are embedded into
an amorphous phase forming a semicrystalline structure and orient themselves in
