10.7 (a) The coupling loss is found from the area mismatch between the fiber-core
end-face areas and the coupling-rod cross-sectional area. If a is the fiber-core
radius and R is the coupling-rod radius, then the coupling loss is
L coupling = 10 log
P out
P in
= 10 log
7π a
2
π R
2
= 10 log
7(25)
2
(150) 2 = −7.11 dB
(b) Similarly, for the linear-plate coupler
L coupling = 10 log 7π a
2
/(length × width) = 10 log
7π(25)
2
800(50)
= −4.64 dB
10.8 (a) The diameter of the circular coupling rod must be 1000 μm. The coupling
loss is
L coupling = 10 log
7π a
2
π R
2
= 10 log
7(100)
2
(500) 2 = −5.53 dB
(b) The size of the plate coupler must be 200 μm by 2600 μm.
The coupling loss = 10 log
7π(100)
2
200(2600)
= −3.74 dB
10.9 n = 9 and N = 2
n
= 512
10.10 (a) 1549, 1550, and 1551 nm;
(b) L 1 = 0.4 mm, L 3 = 0.8 mm
10.11 L 1 = 0.75 mm, L 2 = 1.5 mm, L 3 = 3.0 mm
10.12 λ 1 loss: 2.55 dB, λ 2 loss: 3.15 dB, λ 3 loss: 2.30 dB, λ 4 loss: 1.45 dB
10.13 (a) 523 nm; (b) 1547 nm; (c) 4.2 cm
−1 ; (d) 3.9 nm; (e) 94%
10.14 λ 1 loss: 1.2 dB, λ 2 loss: 1.8 dB, λ 3 loss: 1.4 dB, λ 4 loss: 1.0 dB
