Substituting Eq. (2.9) into Eqs. (2.1) and (2.4) yields Eqs. (2.10) and (2.11):
ρc
∂ T (x
i
, t)
∂t
=
H x i
K [δ]ω(ξ
i j
)ϕ
x
i
, x
j
, t
T
x
j
, t
− T
x
i
, t
ξ
i j
2
dV x i + Q x i ,
(2.10)
ρ ¨
u
x
i
, t
=
H x i
ϕ
x
i
, x
j
, t
f(ξ, η, T, t)dV x j + b
i
.
(2.11)
It is noted that Eq. (2.11) is a dynamic equation. However, the mechanical distortion caused by the changes of temperature should be under a quasi-static process.
Therefore, in order to weaken the dynamic effects of the structure, an artificial
damping method is utilized for the peridynamic equation of motion, which yields
Eq. (2.12):
ρ ¨
u
x
i
, t
+ λ ˙
u =
H x i
ϕ
x
i
, x
j
, t
f(ξ, η, T, t)dV x j + b
i
,
(2.12)
where λ is a damping coefficient obtained by an adaptive dynamic relaxation
technique [28].
On the other hand, it is assumed that 60% of the total heat input of MIG welding
is transferred to the work piece via the molten metal droplets [13], and the total heat
input is calculated by Eq. (2.13):
Q x i = ηV I/V x i ,
(2.13)
where η is the arc efficiency, V is the arc voltage and I is the arc current. In addition,
the heat flux of the molten metal droplets in the Gaussian distribution [9] is adapted
in this paper.
So far, Eqs. (2.10) and (2.12) show the decoupled peridynamic formulations for
the numerical simulation of MIG welding.
