18 Interfacial Materials for Organic Solar Cells
399
Table 18.3
Summary of photovoltaic performance based on representative polymer CIL
Cathode structure
Active layer
Anode structure
V
OC (V) J
SC (mA cm −2
) FF
PCE (%) References
ITO/PEO:ZnO
TQ1:PC
71 BM
MoO
3 /Ag
0.88
9.60
0.67
5.64
Shao et al. (2013)
ITO/PEO:ZnO
PCDTBT:PC
71 BM
MoO
3 /Ag
0.88
11.4
0.65
6.59
Shao et al. (2013)
ITO/ZnO/PEIE
p–DTS(FBTTh
2 )
2 :PC
71 BM MoO
3 /Ag
0.77
15.2
0.67
7.88
Kyaw et al. (2013)
ITO/PEIE protonated
PTB7-Th:IEICO-4F
MoO
3 /Ag
0.70
27.2
0.69 13.2
Xiong et al. (2019)
MSAPBS/Al
PTB7:PC
71 BM
ITO/PEDOT:PSS 0.76
19.2
0.68 10.0
Ouyang et al.
(2015)
DSAPS/Al
PTB7:PC
71 BM
ITO/PEDOT:PSS 0.76
18.2
0.70
9.79
Liu et al. (2016b)
ZnO/DSAPS
PTB7:PC
71 BM
MoO
3 /Al
0.75
17.0
0.70
9.10
Liu et al. (2016b)
ITO/PEI/F
16 CuPc
PTB7:PC
71 BM
MoO
3 /Ag
0.72
20.2
0.66
9.51
Li et al. (2018b)
ITO/ZnO/APTES
PTB7-Th:PC
71 BM
MoO
3 /Ag
0.78
17.1
0.71
9.46
Fu et al. (2017)
ITO/ZnO/APTMS
PTB7-Th:PC
71 BM
MoO
3 /Al
0.80
16.7
0.68
9.07
Wei et al. (2018)
ITO/ZnO/PDEPB
PTB7:PC
71 BM
MoO
3 /Ag
0.73
16.0
0.70
8.14
Nam et al. (2017)
ITO/ZnO/PDEPB
PTB7-Th:PC
71 BM
MoO
3 /Ag
0.79
18.6
0.71 10.4
Nam et al. (2016)
ITO/ZnO/PPy1
PTB7:PC
71 BM
MoO
3 /Ag
0.75
15.3
0.72
8.29
Aryal et al. (2018)
ITO/ZnO/Ppy1
PTB7-Th:PC
71 BM
MoO
3 /Ag
0.81
17.1
0.68
9.37
Aryal et al. (2018)
ITO/PEI/SnO
2 /PFN
PCDTBT:PC
71 BM
MoO
3 /Ag
0.85
14.2
0.60
7.18
Guo et al. (2019)
ITO/P3TBPHT:PEDOTPSS PCDTTPD:PC
71 BM
V
2 O
5 /Al
0.91
11.2
0.55
5.60
Worfolk et al.
(2012)
P3TMAHT:SDS/Al
P3HT:PC
71 BM
ITO/PEDOT:PSS 0.62
9.54
0.68
4.01
Chang et al. (2012)
(continued)
