222
Chapter 7 Using GIS to Make a Map
2. When the map’s ready, select Print from the File pull-down menu—
ArcMap will use this dialog box to send the layout to the printer.
3. Exit ArcMap by selecting Exit from the File pull-down menu. There’s no
need to save any data in this lab.
Closing Time
The geospatial lab application in Chapter 8 will keep using ArcGIS for
analysis—you’ll be using a Web service to take a series of addresses and plot
them on a map, then use those results in ArcGIS for some simple analysis.
Final Layout Checklist
____
The contiguous 48 states (without Alaska and Hawaii) United States
population per square mile, classified, and displayed with an appropriate color scheme
____
States shown in a different (and appropriate) projection than the
default
____
Appropriate map legend, with all items listed with normal names
(the legend should not be called “legend” and should be appropriate
size, font, number of columns, and so on)
____
Scale bar
____
Appropriate title (don’t use the words “map” or “title” in your title)
and appropriate size and font
____
A north arrow of appropriate size and position
____
Type (your name, the date, the source of the data) in an appropriate
size and font
____
Overall map design (appropriate borders, color schemes, balance of
items and placement, and so on)
