PHI SCALE
Joseph F. Donoghue
School of Geology, Oklahoma State University,
Stillwater, OK, USA
Synonyms
Phi grade scale
Definition
The phi scale is a sediment particle size scale, defined as
a logarithmic transformation of the geometric UddenWentworth grain size scale (AGI, 2013). The phi diameter
is calculated as the negative logarithm to the base 2 of the
particle diameter (in millimeters).
Discussion
The phi scale was introduced by Krumbein (1934, 1938)
as a convenient means of visualizing and statistically analyzing sediment grain size distributions over a wide range
of particle sizes. The earlier Udden-Wentworth scale is a
millimeter-based scale, with an unchanging ratio between
class limits. The phi scale allows more emphasis for the
finer grain sizes. Phi size values for the sediment class
limits range from À5 phi (for a diameter of 32 mm, or very
coarse pebble size) down to +10 phi (for a diameter of
1/1,024 mm, or clay size). The scale was developed
specifically as a statistical device to permit the direct
application of conventional statistical practices to
sedimentary data.
The phi scale has distinct advantages over geometric
size scales. Tanner (1969) summarized some of the advantages as follows: geometric basis; equal spacing of size
class divisions, with integers representing the limits of
the Wentworth size classes; simple nomenclature; potential for fine subdivisions; inclusion of a wide range of
grain sizes; wide acceptance; a close match of boundaries
between the three important “super classes” (gravel, sand,
silt + clay) with the widely recognized deficiencies at
about À1 phi (2 mm) and +4 phi (1/16 mm); ease of plotting on ordinary probability axes; adaptability of phi units
to a variety of sophisticated statistical procedures; ease of
interpretation of non-Gaussian data; and ready availability
of sieve screens in standard phi sizes.
Due to its nonlinear and dimensionless nature, the phi
scale presents some challenges in reporting, especially
outside the field of sedimentology. As a consequence,
results are often reported in both phi units and metric units.
Care must be taken in such cases to stipulate how the data
were transformed.
Bibliography
AGI, 2013. Glossary of Geology. American Geosciences Institute.
http://www.agiweb.org/pubs/glossary/#online.
Krumbein, W. C., 1934. Size frequency distributions of sediments.
Journal of Sedimentary Petrology, 4, 65–77.
