102
4 Functions and the Writing of Code
argument f is a Python function for f (t) and N is the number of terms N in the
sum S N (t). The trial function can run a loop where the user is asked for the b n
values in each pass of the loop and the corresponding plot is shown. You must
find a way to terminate the loop when the experiments are over. Use M=500 in
the calls to plot_compare and error.
f) Choose f (t) to be a straight line f (t) =
1
π t on [−π, π]. Call trial(f, 3) and
try to find through experimentation some values b 1 , b 2 , and b 3 such that the sum
of sines S N (t) is a good approximation to the straight line.
g) Now we shall try to automate the procedure in f). Write a function that has
three nested loops over values of b 1 , b 2 , and b 3 . Let each loop cover the interval
[−1, 1] in steps of 0.1. For each combination of b 1 , b 2 , and b 3 , the error in the
approximation S N should be computed. Use this to find, and print, the smallest
error and the corresponding values of b 1 , b 2 , and b 3 . Let the program also plot f
and the approximation S N corresponding to the smallest error.
Filename: fit_sines.py.
Remarks
1. The function S N (x) is a special case of what is called a Fourier series. At the
beginning of the nineteenth century, Joseph Fourier (1768–1830) showed that
any function can be approximated analytically by a sum of cosines and sines.
The approximation improves as the number of terms (N) is increased. Fourier
series are very important throughout science and engineering today.
(a) Finding the coefficients b n is solved much more accurately in Exercise 6.12,
by a procedure that also requires much less human and computer work!
(b) In real applications, f (t) is not known as a continuous function, but function
values of f (t) are provided. For example, in digital sound applications,
music in a CD-quality WAV file is a signal with 44,100 samples of the
corresponding analog signal f (t) per second.
