19
which introduces additional maintenance routines that reduce server uptime. There
is also an environmental impact when using batteries as they must be disposed of
or recycled correctly. It is entirely possible for server or appliance OEMs to include a
battery in their product.
Because some appliance and server vendors plan to use batteries, and because
platforms will someday include the CPU caches in the persistence domain, a property is
available within ACPI such that the BIOS can notify software when the CPU flushes can
be skipped. On platforms with eADR, there is no need for manual cache line flushing.
The Need for Flushing, Ordering, and Fencing
Except for WBINVD, which is a kernel-mode-only operation, the machine instructions
in Table 2-1 (in the “Intel Machine Instructions for Persistent Memory” section)
are supported in user space by Intel and AMD CPUs. Intel adopted the SNIA NVM
programming model for working with persistent memory. This model allows for
direct access (DAX) using byte-addressable operations (i.e., load/store). However, the
persistence of the data in the cache is not guaranteed until it has entered the persistence
domain. The x86 architecture provides a set of instructions for flushing cache lines in
a more optimized way. In addition to existing x86 instructions, such as non-temporal
stores, CLFLUSH, and WBINVD, two new instructions were added: CLFLUSHOPT and
CLWB. Both new instructions must be followed by an SFENCE to ensure all flushes are
completed before continuing. Flushing a cache line using CLWB, CLFLUSHOPT, or CLFLUSH
and using non-temporal stores are all supported from user space. You can find details
for each machine instruction in the software developer manuals for the architecture.
On Intel platforms, for example, this information can be found in the Intel 64 and 32
Architectures Software Developer Manuals (https://software.intel.com/en-us/
articles/intel-sdm).
Non-temporal stores imply that the data being written is not going to be read again
soon, so we bypass the CPU caches. That is, there is no temporal locality, so there is no
benefit to keeping the data in the processor’s cache(s), and there may be a penalty if the
stored data displaces other useful data from the cache(s).
Flushing to persistent memory directly from user space negates calling into the
kernel, which makes it highly efficient. The feature is documented in the SNIA persistent
memory programming model specification as an optimized flush. The specification
Chapter 2 persistent MeMory arChiteCture
which introduces additional maintenance routines that reduce server uptime. There
is also an environmental impact when using batteries as they must be disposed of
or recycled correctly. It is entirely possible for server or appliance OEMs to include a
battery in their product.
Because some appliance and server vendors plan to use batteries, and because
platforms will someday include the CPU caches in the persistence domain, a property is
available within ACPI such that the BIOS can notify software when the CPU flushes can
be skipped. On platforms with eADR, there is no need for manual cache line flushing.
The Need for Flushing, Ordering, and Fencing
Except for WBINVD, which is a kernel-mode-only operation, the machine instructions
in Table 2-1 (in the “Intel Machine Instructions for Persistent Memory” section)
are supported in user space by Intel and AMD CPUs. Intel adopted the SNIA NVM
programming model for working with persistent memory. This model allows for
direct access (DAX) using byte-addressable operations (i.e., load/store). However, the
persistence of the data in the cache is not guaranteed until it has entered the persistence
domain. The x86 architecture provides a set of instructions for flushing cache lines in
a more optimized way. In addition to existing x86 instructions, such as non-temporal
stores, CLFLUSH, and WBINVD, two new instructions were added: CLFLUSHOPT and
CLWB. Both new instructions must be followed by an SFENCE to ensure all flushes are
completed before continuing. Flushing a cache line using CLWB, CLFLUSHOPT, or CLFLUSH
and using non-temporal stores are all supported from user space. You can find details
for each machine instruction in the software developer manuals for the architecture.
On Intel platforms, for example, this information can be found in the Intel 64 and 32
Architectures Software Developer Manuals (https://software.intel.com/en-us/
articles/intel-sdm).
Non-temporal stores imply that the data being written is not going to be read again
soon, so we bypass the CPU caches. That is, there is no temporal locality, so there is no
benefit to keeping the data in the processor’s cache(s), and there may be a penalty if the
stored data displaces other useful data from the cache(s).
Flushing to persistent memory directly from user space negates calling into the
kernel, which makes it highly efficient. The feature is documented in the SNIA persistent
memory programming model specification as an optimized flush. The specification
Chapter 2 persistent MeMory arChiteCture
