6.2.4 Nonlinear Dynamics and Hopf Bifurcations Without
Parameters
Let us study the dynamics of the M −C −L circuit in the (ϕ, q)-domain. The unique
EP of (6.30) is given by ¯
x = h(Q 0 ) and ¯
y = Q 0 . The Jacobian of the vector field
defining (6.30) at the EP is
J ( ¯
x, ¯
y) =
0 −
1
C
1
L −
h (Q 0 )
L
=
0 −
1
C
1
L
a−3bQ 2
0
L
.
(6.34)
By denoting with
α = trJ ( ¯
x, ¯
y) =
a − 3bQ 2
0
L
Δ = detJ ( ¯
x, ¯
y) =
1
LC
> 0
the eigenvalues of J ( ¯
x, ¯
y) are
λ 1,2 =
−α ±
√
α 2 − 4Δ
2
.
(6.35)
For α = 0, i.e., Q 0 = ±
√
a/3b, the vector field defining (6.30) is in Normal
Form and the linearization at the EP exhibits a center (i.e., a pair of purely imaginary
eigenvalues λ 1,2 = ±j
√
Δ). By evaluating the real and imaginary part of the
eigenvalues λ 1,2 , we can easily conclude the following.
1. If α < 0, i.e.,
|Q 0 | <
a/3b
then the unique EP is unstable (J ( ¯
x, ¯
y) has two eigenvalues with positive real part)
and it is seen that (6.30) presents persistent oscillations. For verification, Fig. 6.20
reports the real and imaginary parts of the eigenvalues λ 1,2 in (6.35) as a function
of Q 0 when the circuit parameters are C = 9/2, L = 1, a = 1, and b = 1/3.
2. If α > 0, i.e.,
|Q 0 | >
a/3b
then the unique EP is asymptotically stable (J ( ¯
x, ¯
y) has two eigenvalues with
negative real part—see Fig. 6.20). It is seen that (6.30) exhibits no oscillatory
behavior and the only EP is also globally attracting for the trajectories.
