meeting requirements for various interconnect domains (e.g. sensors, memory-onlogic and higher-IO density logic-on-logic) and applications (automotive, mobile,
client, server). Adoption of new technology is not solely a technical challenge but also
a business challenge which involves new equipment investments and timely introduction to enable adequate product volumes for high volume manufacturing (HVM).
Eliminating solders and solder intermetallic compounds (IMC’s) seems promising,
however Cu-only interconnects are also prone to electromigration. Cu alloying and
doping evolving from SAB methods, new protective layers and novel processing
[83] and Cobalt demonstrations have been researched [84] and in special cases also
deployed [85]. In the long term, advanced materials (e.g. 2D/nanomaterials) may be
introduced as auxiliary materials for Cu–Cu enabling or even as key interconnect
materials with potential to replace Cu altogether [86]. As Prof. Feynman once said:
“There is plenty of room at the bottom.”
