152
R. Mattana et al.
heavy metals, semiconductors, insulators, topological insulators, etc.) and devices
are currently investigated. In this paragraph, we aim at discussing the spin-charge
conversion using topological insulators as well as the heat-spin current conversion
in ferromagnetic insulator/paramagnetic metal devices.
5.2.2.1 Spin-Charge Conversion
Conversion between charge and spin currents has been a very active branch of spintronics in the last couple of years. Such a conversion can be achieved in bulk materials
(the so-called spin Hall effect) or at interfaces (Edelstein–Rashba effect) relying on
the spin–orbit interaction and/or extrinsic effects. The studied materials are usually
NM metals with a large spin–orbit coupling. A second approach is to rely on spin–
orbit properties at the interfaces either at Rashba interfaces or through the surface
states of topological insulators (TIs). A complete review of this approach can be
found in J. Sinova et al. [44] or A. Soumyanarayanan et al. [36].
In the following, we provide an example where angle-resolved photoemission
spectroscopy (ARPES) measurements have allowed to understand the spin-charge
conversion from the α-Sn TI [see Fig. 5.14a]. In this spin-charge conversion study,
the spin current is generated through the magnetization dynamics induced at the
magnetization resonance of a Fe layer by an external rf field. The generated spin
current then diffuses to the α-Sn top surface. Injection of a spin current into a TI
induces a spin accumulation on one side of the Fermi contour of the Dirac cone as
well as a spin depletion on the other side [see Fig. 5.14b]. As a consequence, this spin
injection results in a charge current. Importantly, note that the spin-charge conversion
is not observed when Fe is deposited directly on α-Sn, but is observed when a thin Ag
layer is inserted at the interface [see Fig. 5.14c]. By performing ARPES measurement
to probe the DOS, it has been shown that the deposition of a sub-monolayer of Fe
on α-Sn indeed suppresses the Dirac cone, that is a signature of the TI, whereas it
is still observable after deposition of a Ag layer [see Fig. 5.14d]. Hence the absence
of spin-charge conversion at Fe/α-Sn interfaces is clearly ascribed to the loss of TI
surface states after the Fe deposition. This study shows that characterization of the
DOS by ARPES measurements is a very useful and unique technique to understand
spin-charge conversion at such spinorbitronic interfaces.
5.2.2.2 Heat-Spin Conversion
Similarly to the Seebeck effect, the spin Seebeck effect describes the generation of a
spin voltage from a temperature gradient in a FM conductor or insulator. Longitudinal
spin Seebeck effect (LSSE) refers to experiments where the spin current generated
is parallel to the temperature gradient. Materials used are FM materials (conducting
