5.4 Excited Third Generation Quarks
175
signal and background contributions are fit to the data in the signal and control regions
simultaneously. The combination of the +jets and dilepton final states results in a
lower mass limit of 1.5 TeV for vector-like b
∗ couplings.
An analysis by CMS using 8 TeV data combines the all-hadronic, +jets and
dilepton channels in the search for b
∗
→ W t [980]. While the +jets and dilepton
channels target resolved topologies with exactly three and exactly one small-R jet,
respectively, the all-hadronic selection is optimised for fully merged final states.
This selection is based on two large-R jets with p T > 425 GeV, where one is W
and the other one is t-tagged. The W tagging uses the pruned jet mass and τ 21 ;
t tagging is achieved with the CMSTT, τ 32 and a subjet b tag.
The dominant
backgrounds in the leptonic final states are estimated from simulation and validated
in control regions. In the all-hadronic final state, the dominant multijet background
is obtained by weighting events prior to the t tagging selection with the t-tagging
misidentification rate. This misidentification rate is calculated as a function of jet
p T and η in a sample dominated by multijet events, obtained by inverting the W
selection criteria. Because the t tagging algorithm has a misidentification rate of about
0.1% [243], the background obtained from the weighted pre-t-tagged sample can be
considered statistically independent from the sample after the t tagging selection
has been applied. The sensitivity to signals for b
∗ masses below 1 TeV is driven
by the +jets and dilepton channels, but for higher masses the all-hadronic analysis
provides better sensitivity. Similar to the 8 TeV analysis by ATLAS, lower mass limits
of 1.5 TeV for vector-like b
∗ couplings are obtained.
A very recent analysis by CMS uses the full 13 TeV data with 137 fb
−1 to search
for b
∗
→ W t in the all-hadronic final state, targeting b
∗ masses >1.2 TeV [981].
The analysis uses two large-R jets with p T > 400 GeV and an angular separation
in azimuth greater than π/2 to ensure a back-to-back topology of the two jets. The
signal region is defined through a W - and a t-tagged jet. Both taggers use soft drop jet
mass, where t jets in the signal region are required to have 105 < m jet < 220 GeV
and W jets 65 < m jet < 105 GeV. In addition, τ 32 and subjet b tagging is used for the
definition of t jets, and τ 21 for W jets. The analysis is performed in two dimensions,
where the distribution in the plane (m t , m W t ) is analysed for a potential signal. Note
that a region in m t between 65 and 285 GeV is analysed, such that the signal region
with 105 < m jet < 220 GeV is enclosed by a low- and a high-mass sideband. In this
analysis, m t is the soft drop mass of the t jet and m W t is the mass of the dijet system.
This allows for the use of a novel method to construct the multijet background
template, which relies on a parametrisation of the pass-fail ratio as a function of m t .
The number of multijet events passing the t tagging requirement, n p , in a given
interval in the (m t , m W t ) plane is calculated as n p = n F · f (m t , m W t ), where n F is
the number of events failing the t tagging requirement and f (m t , m W t ) is the twodimensional pass-fail ratio. This ratio is obtained from data, with an initial estimate
obtained from simulation in order to reduce the complexity of the function. It is found
that a a surface parametrised by the product of a second-order polynomial in m t and a
first-order polynomial in m W t is sufficient to describe the data in the sideband regions.
The advantage of this method is that it interpolates the pass-fail ratio into the signal
region from the enclosing sidebands, such that the analysis can be fully tested and
