that is close to unfolding transition state (Fig. 24b). To be able to reach the
unfolding transition state, the sample needs to be pre-heated to a temperature of
63°C. This pre-heating of the sample is necessary since comparable T-jumps do not
lead to unfolding of the protein at lower temperatures. The T-jump induces a barrier
shift towards the folded state (F), leading to a downhill unfolding (U) of a part of the
sample (A in Fig. 24b). Afterwards, a remaining sub-ensemble can unfold by
overcoming the shifted energy barrier on a longer timescale (B in Fig. 24b).
Figure 24c shows the corresponding 2D IR spectrum at elevated temperature in the
amide-I spectral range, which is characterized by intense diagonal peaks and weak
cross peaks (arrows). The two beta-sheet modes lie at positions of 1642 cm
-1 (m \ )
and blue 1676 cm
-1 (m k ), respectively. A change in the stationary sample
temperature (Fig. 24d) leads to disruption of the beta-sheet of ubiquitin. This is
observed by a blue-shift of the m \ mode, which can be best visualized in a difference
2D IR signal between the two temperatures (red arrows in Fig. 24e). The blue and
green arrows indicate an increase in the random-coil structure and a depletion of the
cross peak signals, respectively. Figure 24f–k demonstrates, how the accompanied
structural changes in the molecules can be tracked with transient 2D IR T-jump
spectroscopy. At short T-jump delays (100 ns), the T-jump difference spectrum
shows predominately temperature-induced disruption of H-bonds (red ellipse),
which cause a blue-shift of the sheet vibrations. Following that initial response, the
difference spectra gradually evolve up to delays as large as 7 ms, (g)–(k), where
almost a quantitative agreement with the stationary difference spectrum, (e), is
obtained. Through a kinetic analysis of a full series of such T-jump 2D IR spectra,
as well as a comparison with MD simulations, it was possible to obtain a detailed
understanding of the progressive unfolding mechanism of ubiquitin. It was revealed
that ubiquitin unfolds in three distinguishable phases, i.e. a first stage of thermal
excitation of the solvent, a second stage of microsecond downhill unfolding, and a
third stage of ms-unfolding over a barrier (Fig. 24b). Based on the close matching of
experimental and MD simulation results it was furthermore proposed that the
T-jump 2D IR spectroscopy can be used to discriminate between different
theoretically proposed unfolding pathways.
T-jump 2D IR spectroscopy has also been used to study structural changes of
other biological sample systems. Also, Tokmakoff et al. have studied the folding
mechanism of the N-terminal domain of ribosomal proteins and compared the
experimental results to Markov-state based MD-simulations [262]. Native and
denaturized structures could be correctly predicted and time-constants for the
temperature-induced interconversion were successfully modeled. Other applications
by the same group considered protein-protein binding and T-jump induced
dissociation dynamics of insulin homodimers [271]. A detailed comparison of the
observable kinetics at different starting temperatures indicated that the dissociation
is characterized by two processes, the influence of which varies with temperature.
Future applications of T-jump 2D IR spectroscopy are moreover likely to involve
combinations of T-jump 2D IR spectroscopy with other established methods such
isotope labelling and site-specific mutations. Finally, additional future experiments
may involve addressing distinguishable conformational states in the folded and
unfolded states of various proteins, as well timescales of exchange between them.
