Abstract
This introduction to crude oil and petroleum processing provides a working
knowledge of crude oil properties and refining to make the large array of
petroleum-based products we enjoy today. Topics include the composition of
crude oil, the crude assay, product properties, and the basic processes used to
convert crude to useful products. This chapter sets the stage for the detailed
discussions, descriptions, and calculation methods contained in the balance of
this handbook.
Keywords
Refinery • Refining • Petroleum • Crude oil
Introduction
The wheel, without doubt, was man’s greatest invention. However, until the late
eighteenth century and early nineteenth century, the motivation and use of the
wheel was limited either by muscle power, man or animal, or by energy naturally
occurring from water flow and wind. The invention of the steam engine provided,
for the first time, a motive power independent of muscle or the natural elements.
This ignited the industrial revolution of the nineteenth century, with its feverish
hunt for fossil fuels to generate the steam. It also initiated the development of the
mass production of steel and other commodities.
Late in the nineteenth century came the invention of the internal combustion
engine with its requirement for energy derived from crude oil. This, one can say,
4
D.S.J. Jones
