19. Refrigerated centrifuge.
20. Mini PROTEAN Tetra system.
21. Semidry transblot system.
22. Heater.
2.4 Detection
of Native HBV Antigens
1. ELISA—Monolisa HBsAg ULTRA kit (Bio-Rad) (see Note 5).
2. Multichannel pipette.
3. 96-well plate absorbance reader.
2.5 Antigen
Purification
1. Sucrose solutions: 15%, 20%, 25%, 35%, 45%, and 60% sucrose
in water. All solutions are heat-sterilized and stored at 4
C (see
Note 6).
2. Ultracentrifuge (SW32Ti and SW41Ti rotors).
3. Ultracentrifuge tubes.
4. Vortex.
5. Dialysis membranes, 10 MWCO.
6. Liquid nitrogen.
7. Lyophilizer.
3 Methods
Perform all steps at room temperature, unless otherwise indicated.
3.1 Small-Scale HBV
Antigen Expression
1. Seed 5 Â 10
5 HEK293T cells in 6-well plates; add 2 mL of
complete DMEM and grow in a CO 2 incubator for 24 h.
2. Replace cell media with 2 mL of fresh DMEM and transfect
cells with either pCi-S or pCi-S/preS1
21–47 plasmids, using a
mixture of 200 μL TB, 6 μL TR, and 2 μg plasmid DNA per
well (see Note 7). Keep nontransfected HEK293T cells as a
control (see Note 8).
3.2 Biochemical
Characterization
of HBV Antigens
1. Harvest the HEK293T cells and supernatants at 48 h
posttransfection.
2. Briefly collect cells by centrifugation at 1200 Â g for 2 min then
incubate resulting pellets with lysis buffer, for 30 min, on ice.
3. Clarify lysates by centrifugation at 10,000 Â g, for 10 min, at
4
C. Determine the total protein concentration using the BCA
kit, as indicated by the supplier.
4. To monitor the N-glycosylation status of HBV proteins, treat
samples either with PNG-ase F or EndoH enzymes, following
the protocol provided by the supplier (see Note 9).
5. Heat-denature sample volumes (equivalent of 30 μg of total
protein/lane) and molecular standards (equivalent of 2 μg protein/lane) in the presence of either nonreducing or reducing
SDS sample loading buffer, at 95
C, for 5 min (see Note 10).
HBV Surface Antigens in Mammalian Cells
87
