primary amines) on a gold surface. The surface
is functionalized through a process of incubation in the given solutions, and QCM is then
used for the immobilization of the antibody
itself. Give details as to why and how each
material binds to the underlying layer. Qualitatively predict what the QCM mass versus time
profiles will look like for each deposition step.
Materials: (a) An aqueous solution of 1-ethyl3-[3-dimethylaminopropyl]carbodiimide hydrochloride (or EDC), (b) mercaptoundecanoic acid
in anhydrous ethanol, (c) an aqueous solution
of (NHS), and (d) a gold-coated substrate.
4. Consider the fabrication of a polyelectrolyte
multilayer composed of PEI and PAZO on a
glass substrate. After each deposition step, the
mass of the film can be measured by QCM and
thickness by ellipsometry. Predict how these
values change for a 10-bilayer film as the following parameters are varied: (a) Decreasing
the pH of the polyelectrolyte solution from 7 to
4, (b) increasing the salt concentration from 0
to 100 mM, and (c) increasing the deposition
temperature from 25°C to 30°C. For (a) you will
need to look up various pK values for groups on
each polyelectrolyte.
