298
14 Amplitude Factorization and Feynman Diagrams
The second condition is satisfied automatically because the Hilbert space is H −
when working with ˆ
P g,n (Sect. 13.3.1). However, the first condition further restricts
the states that propagate in internal lines. This leads to postulate that the external
states should also be taken to satisfy this condition
b
+
0 |V i = 0,
(14.50)
since external states are usually a subset of the internal states. This provides another
motivation of the statement in Sect. 3.2.2 that scattering amplitudes for the states not
annihilated by b
+
0 must be trivial. A field interpretation of this condition is given in
Chaps. 10 and 15.
Under these constraints on the states, the propagator can be inverted:
−1
= c
+
0 c
−
0 L
+
0 δ L
−
0 ,0 .
(14.51)
14.2.3 Fundamental Vertices
The vertices (14.33) can be constructed recursively assuming that all amplitudes are
known. The starting point is the tree-level cubic amplitude A 0,3 : since it does not
contain any internal propagator, it is equal to the fundamental vertex V 0,3 .
The first thing to extract from the recursion relations are the background
independent data. This amounts to find local coordinates and a characterization of
the subspaces V g,n ⊂ M g,n , starting with P 0,3 and iterating.
In the rest of this section, we show how this works schematically.
Recursive Definition: Tree-Level Vertices
The description of tree-level amplitudes A 0,n is the simplest since only the
separating plumbing fixture is used and Feynman graphs are trees. The possible
factorizations of the amplitude correspond basically to all the partitions of the set
{V i } into subsets.
Tree-Level Cubic Vertex Since M 0,3 = 0, the moduli space of the 3-punctured
sphere 0,3 reduces to a point, and so does the section S 0,3 of P 0,3 (Fig. 14.4a):
V 0,3 (V 1 , V 2 , V 3 ) := A 0,3 (V 1 , V 2 , V 3 ) = ω
0,3
0 (V 1 , V 2 , V 3 ).
(14.52)
The corresponding graph is indicated in Fig. 14.4b.
Tree-Level Quartic Vertex Part of the contributions to the 4-point amplitude A 0,4
with external states V i (i = 1, . . . , 4) comes from gluing two cubic vertices.
Because there are four external states, there are three different partitions 2|2 that
are described in Fig. 14.5 (see also Fig. 12.7). The sum of these three diagrams does
