migrates to the longest distance on the gel. However, in the
presence of a protein/peptide which can specifically bind to this
DNA fragment, the protein binds to DNA and forms stable
protein/DNA complexes. The migration of these larger protein/
DNA complexes is retarded or shifted on the gel since they move
more slowly than the unbound DNA (Fig. 1a). There will be a
tendency to show the more protein concentration added to a fixed
concentration of DNA probe, the more shifted protein/DNA
complexes accumulate. These increasing protein/DNA complexes
will ultimately reach a plateau, once DNA is fully bound and
saturated by protein (Fig. 1b).
7. Gel retardation assay revealed that N/P ratio-dependent interactions between CPP and DNA were maximized at N/P ratios
above 12 [8].
8. Cells are grown and maintained in a 100-mm tissue culture
dish with 10 mL culture medium routinely. Cells can be seeded
in 24-well culture plates for fluorescent image studies, and the
final reaction volume is 150 μL of L5a/DNA complexes. Suspension cell culture has not been tested, but CPPs should
penetrate most cells.
9. The presence of 10% FBS in media reduces the efficiency of
complexing CPPs with the cargos leading to a decrease in the
uptake of CPPs or their complexes/conjugates [16].
10. The efficiency of the EGFP reporter gene expression in the cells
can be quantified by the flow cytometric analysis, or semiquantified by the intensity of fluorescent images [8]. As stated
above, the green fluorescent intensity can be converted and
semi-quantified using the UN-SCAN-IT or ImageJ software.
For instance, the transfection efficiency of L5a-mediated delivery
of the EGFP reporter gene expression showed approximately
41-fold increase compared to the negative control in A549
cells, while the transfection efficiency of Lipofectamine 2000mediated delivery of gene expression showed about 64-fold
increase compared to the negative control [8].
Acknowledgments
This work was supported by the Center for Biomedical Research at
Missouri University of Science and Technology, and the Ministry of
Science and Technology, Taiwan.
