274
Y. Xu et al.
q i
refers to the flowrate of each CSs, m3/h
p max
i
refers to the maximum design pressure of a pipe network, MPa
p min
i
refers to the minimum pressure of a pipe network, MPa
P max
i
refers to the maximum operation power of CSs, kw
P min
i
refers to the minimum operation power of CSs, kw
M
is a sufficiently large positive constant
MI
is a sufficiently small positive constant
Decision variables
D P
i,j
is a binary variable, if one pipeline start from node i to node j was chosen,
then D P
i,j = 1, and D P
i,j = 0 otherwise.
D i,j,d
is a binary variable, if one size of pipe starts from node i to node j was chosen,
then D i,j,d = 1, and D i,j,d = 0 otherwise
D C
i
is a binary variable, if compressors would be constructed, then D C
i = 1 and
D C
i = 0 otherwise
NP
upper
i
is a binary variable, if the pressure exceeds the upper pressure limitation, then
NP
upper
i
= 1, and NP
upper
i
= 0 otherwise
NP blow
i
is a binary variable, if the pressure exceeds the upper pressure limitation, then
NP blow
i
= 1, and NP blow
i
= 0 otherwise
NP
upper
i
is a binary variable, if the pressure exceeds the lower pressure limitation, then
NP
upper
i
= 1, and NP
upper
i
= 0 otherwise
P c
refers to the power of compressors in original CSs, kw
P C
refers to the power of newly built compressors, kw
P T
refers to the power of throttle loss in CSs, kw
