more sophisticated than of 2D images, the proposed methods help to understand morphological influences on important phenomena like crystal growth, agglomeration
and breakage.
Another aspect of the work was the modeling of crystallization under consideration of the influence of morphology. Using a high dimensional population balance
model the important influence of multiple surfaces with different growth rates on crystal growth was demonstrated. For the effective solution of such a model, novel numerical methods have been developed. It is common practice to neglect the combined
influence of agglomeration and growth on the surface area of crystal populations. It
was herein demonstrated that this introduces high errors in such models. A method
was proposed to parametrize a population balance model that considers both the
evolution of crystal volume and area correctly. Because such models are still numerically challenging and computationally expensive even if not included in a flowsheet,
they are currently not suitable for simulation of integrated flowsheets. Therefore, a
simpler model was included in the simulation platform Dyssol. It is demonstrated
that Dyssol can be used to efficiently calculate integrated crystallization processes.
