impact velocity before the impact. Thus, distributions of the relative particle impact
velocity, i.e. of the acting stress energies and stress frequencies in the process were
obtained. These experiments clearly confirmed the impression of the breakage modes
from SEM images of the glass spheres: A high number of impacts occurs during the
process in the mill, while at the same time, the mean relative particle impact velocity
is surprisingly low.
Finally, a product mass flow model of Köninger was presented. Based on an
adaption of the breakage model of Vogel and Peukert, and using the mean relative
particle impact velocity determined by the particle probes, this model provides a
reasonable approximation of the experimental data.
Acknowledgements We would like to thank the group of Prof. Weber from TU Clausthal for
the fruitful collaboration on classification within the priority program 1679. The support of the
Center of Functional Particle Systems is acknowledged as well. The German Research Foundation
is acknowledged for funding through the DFG priority program 1679 “Dynamic Simulation of
Interconnected Solids Processes”.
