G. C. Ghivela et al.
Table 3 Computed resonant frequency
f (in THz) Si
Ge
WzGaN
GaAs
InP
ω r (×10 7
rad/s)
ω r (×10 7
rad/s)
ω r (×10 7
rad/s)
ω r (×10 7
rad/s)
ω r (×10 7
rad/s)
0.094
9.51
7.352
9.52
4.556
0.851
01
9.36
7.227
8.03
4.474
0.82
02
8.588
7.07
7.662
4.18
0.776
04
8.071
6.775
7.452
4.007
0.592
06
7.418
6.177
7.01
3.774
0.46
08
7.037
6.009
7.75
3.579
0.397
10
6.816
5.611
7.37
3.447
0.353
12
6.613
5.413
7.12
3.291
0.313
14
6.434
5.2
6.928
3.070
0.267
16
6.184
4.776
6.675
2.856
0.202
18
6.033
4.617
6.356
2.732
0.164
20
5.882
4.455
5.129
2.544
0.149
22
6.04
4.5
5.054
2.612
0.165
24
6.019
4.5
5.012
2.666
0.169
26
5.895
4.516
4.96
2.697
0.155
28
5.872
4.614
4.851
2.739
0.151
30
5.859
4.674
4.803
2.78
0.718
