2 Description of the Wolfram SystemModeler
Fig. 2.54 Entering the numeric values of the parameters of the SpringDamper component
Fig. 2.55 View component “Fixed”
Fig. 2.56 Enter the numeric values of the parameters of the component “Fixed”
As a result, switching to the text mode, we see the finished program with explicitly
defined connections between the components, as shown in Fig. 2.57.
Let’s go into the mode of performing a numerical experiment. We construct in
one axis the graphs of the displacement and velocity of the body in two models. We
see almost complete overlay of the corresponding graphs, as shown in Fig. 2.58.
