Thus, the analysis of SKTS taking into account the above criteria for the analysis
of SKTS structural logic circuits will be carried out by setting the criteria for interpreting SKTS structural logic circuits and performing a number of actions aimed at
determining the type of tabular structure, forming SKTS structural logic circuits and
requesting input of objects ODR in OKB, which will allow for targeted cell traversal
on specified types of table structures and generate requests for entering ODR objects
in OKB.
Thus, the sequence of the SKTS analysis method based on targeted enumeration, taking into account the above criteria for the analysis of SKTS structural logic
schemes, will be as follows:
1. Preliminary analysis of SKTS, aimed at determining the type of table structure
used to organize the contents of SKTS and checking the possibility of machine
analysis of SKTS in order to generate a request for entering ODR objects in
OKB.
2. The formation of the structural logic diagram of the SKTS header by analyzing the
structural features of SKTS based on the analysis criteria of the SKTS structural
logic diagrams.
3. The formation of the structural logic diagram of the SKTS dataset in accordance
with the method of graphical structuring of tabular data used in SKTS.
4. Establishing correspondence between header cells and data cells to create a
connection between data and information describing them by analyzing their
structural logic diagrams.
5. Determination of the symbolic name of the ODR object by analyzing the SKTS
structural logic diagram to generate a request for entering objects in the OKB.
6. Determination of the structural-logical schemes of properties by analyzing the
structural-logical scheme of the SKTS header based on the criteria for interpreting
the types of header cells according to their structure according to expression (21).
7. Determining the ownership of properties of ODR objects by correlating the
contents of header cells containing the properties of the ODR object with the
contents of header cells containing the symbolic names of ODR objects in
accordance with the method of graphical structuring of tabular data used in SKTS.
8. Formation of a request to enter ODR objects in OKB by composing the structurallogical diagrams of property-values, property-objects and the symbolic name of
the ODR object into a single structure.
Steps 1–4 are intended for the formation of the SKTS structural logic diagram,
further processing of which will allow generating a request for entering ODR objects
in OKB, as well as instances of ODR objects that make up the contents of SKTS.
Steps 5–8 are intended for processing the SKTS structural logic diagram obtained
in the previous steps to generate a request to OKB to enter ODR objects from which
OKB will be generated.
