220
11 Liquid Phase
changes the system energy, but fluctuation contributes little to the system energy on
average.
It is essential to treat water as a crystalline–like structure with well–defined lattice
geometry, strong correlation, and high fluctuation. For a specimen containing N
oxygen atoms, there will be 2N numbers of protons H
+ and lone pairs “:” to form the
O:H–O bonds uniquely, except for the dangling H–O radicals and the dangling lone
pairs at the network terminals. The 2N numbers and the O:H–O bond configuration
conserve regardless of structural phase [49] unless excessive H
+ or “:” is introduced.
The H
+ or the “:” cannot stay alone of moving freely but attach to a H 2 O.
Excessive H
+ injection by acid solvation will bond to a H 2 O to form the H 3 O
+
hydronium and the H↔H anti–HB [50]. Base or H 2 O 2 solvation introduces excessive
number of “:” in the form of HO
− hydroxide that form the O:⇔:O super–HB with
one of its neighboring H 2 O [51]. The H 3 O
+ or the HO
− replaces the central H 2 O in
Fig. 11.1a but the neighboring H 2 O remain their orientations because of the lattice
geometry and interactions with other neighboring H 2 O molecules. The H 3 O
+ or the
HO
− may undergo Brownian motion or drift diffusion under a graded electric or
thermal field.
The motion of a H 2 O molecule or the proton H
+ transportation is subject to
restriction. If the central molecule rotate above 60° around the C 3v symmetrical axis
of the 2H 2 O unit cell, an H↔H and O:⇔:O repulsion will come into play, which is
energetically forbidden. Because of the H–O bond energy of ~4.0 eV, translational
tunneling of the H
+ between adjacent H 2 O molecules is also forbidden. In fact, only
can 121.6 nm wavelength laser radiation breaks the H–O or the D–O bond in the
vapor phase [52, 53]. The 121.6 nm wavelength corresponds to 5.1 eV energy that is
greater than the 4.0 eV estimated by resolving the T C − P profiles of ice Regelation
[54, 55]. The least molecular coordination number of the gaseous monomer shortens
and stiffens the H–O bond most.
11.2.2 O:H–O Bond Potentials and Cooperativity
Figure 11.1b illustrates the asymmetrical, short–range, coupled three–body potentials
for the segmented O:H–O bond [44, 45]. The proton serves as the coordination origin.
The left–hand side is the O:H van der Walls (vdW) interaction and the right–hand
side is the H–O polar-covalent bond. The Coulomb repulsion between electron pairs
on neighboring O
2− couple the O:H–O bond to be an oscillator pair.
The O:H nonbond and the H–O bond segmental disparity and the O–O coupling
dislocate the O
2− of the segmented O:H–O bond in the same direction but by different
amounts under an external stimulus, see Fig. 11.1c. The softer O:H nonbond always
relaxes more than the stiffer H–O bond with respect to the H
+ as the coordination
origin. The ∠O:H–O angle θ relaxation contributes mainly to the geometry and
mass density. The O:H–O bond bending has its specific vibration mode that does
not interfere with the H–O and the O:H stretching vibrations [1]. The O:H–O bond
cooperativity determines the properties of water and ice under external stimulus such
