598
K. Kleinknecht and U. Uwer
is obtained [87] which corresponds to a value of the phase β of,
β = (21.9 ± 0.7)
◦ or β = (68.1 ± 0.7)
◦ ,
where the ambiguity is not resolved.
9.6.5.2 B 0
s Meson
Analogue to the measurement of the CKM phase β in the B 0 system, the measurement of a corresponding CP violating phase β s , defined in Sect. 9.7, can be
performed in the B 0
s system, assuming that the B 0
s oscillation can be resolved. The
golden channel used is the decay B 0
s → J/ψφ. Due to its higher mass the B 0
s system
cannot be produced at the ϒ(4S) resonance and β s was therefore not accessible at
the B-factories.
The two Tevatron experiments CDF and D0 have performed explorative studies
of the decay B 0
s → J/ψφ [102, 103] and also first measurements [104, 105] but
the results have been limited by the number of recorded signal events. The first
significant measurement of the phase 6 φ s = −2β s has been presented by the LHCb
experiment in 2011 [106].
In the decay B 0
s → J/ψφ the final-state is composed of two vector particles
and angular momentum conservation allows for the relative angular momentum
values L = 0, 1 or 2. The final-state J/ψφ is thus not a pure CP-state but a
linear combination of CP-even and CP-odd eigenstates depending on the relative
angular momentum L of the two vector mesons: η CP = η CP (J /ψ)η CP (φ)(−1) L =
(−1) L . The measurement of the time dependent CP asymmetry requires a separate
treatment of the CP-odd and CP-even states which can be achieved statistically by
analyzing the angular distribution of the final-state particles J/ψ → μ + μ − and
φ → K + K − . To measure the angular distribution of the final state particles it is
common to use the helicity basis. The three decay angles necessary to describe the
decay are denoted by (θ K , θ μ , ϕ h ) and are defined in Fig. 9.31. The polar angle θ K
(θ μ ) is the angle between the K + (μ + ) momentum and the direction opposite to the
B 0
s momentum in the K + K − (μ + μ − ) centre-of-mass system. The azimuthal angle
between the K + K − and μ + μ − planes is ϕ h .
The analysis of the B 0
s → J/ψφ events is further complicated by a small
fraction of non-resonant B 0
s → J/ψK + K − decays (CP-odd) which interfere with
the φ meson decaying to two charged kaons. These non-resonant events need to be
considered. Effectively one therefore studies B 0
s decays to J/ψK + K − .
6 In the Standard Model the phase φ s determined by the measurement of the time-dependent CP
asymmetry in the decay B 0
s → J/ψφ equals in leading order to −2β s with β s being defined in
Sect. 9.7. However, in case of new physics effects the two phases could differ. In the context of this
textbook these differences are ignored.
