504
F. Bordry et al.
Fig. 8.105 Fiducialisation of a CMS big wheel by photogrammetry
BCAM has been developed. The design of the lines of sight has been chosen either
vertical or parallel to the movement of the detectors so that the BCAM can measure
the most critical deviations during the movement of the detectors.
References
1. R.A. Beth: Complex representation and computation of two-dimensional magnetic fields, J.
Appl. Phys. 37(7) (1966) 2568.
2. H.D.Glass: Permanent magnets for beamlines and the recycler ring at Fermilab, FERMILABCONF-98-267
3. D. Tommasini et al., “Design, Manufacture and Measurements of Permanent Quadrupole
Magnets for Linac4,” IEEE Trans. Appl. Superc., v. 22, n. 33, Jun. 2012
4. C. Benabderrahmane, J. C. Biasci, J. F. Bouteille, J. Chavanne, L. Farvacque, L. Goirand,
G. Le Bec, S. M. Luizzo, P. Raimondi, and F. Villar, Magnetf for the ESRF-EBS Project,
Proceedings of the 7th International Particle Accelerator Conference, Busan, Korea (JACoW,
Geneva, 2016), p. 1096.
5. P. Thonet, Use of Permanent Magnets in Multiple Projects at CERN, IEEE Trans. Appl.
Supercond. 26 (2016) 4101404
6. B.D. Montgomery: Solenoid Magnet Design, Wiley-Interscience 1969, Krieger Publ. Co.
1980.
7. R.R. Wilson: The Tevatron, Fermilab Report TM-763, 1978.
