to detect β-gal and other enzymatic activities. The core 2-arylbenzothiazole
derivatives were highly fluorescent, and this had been rationalized by ESIPT
process. When combined with the enzymic substrates, the ESIPT effect of
2-arylbenzothiazole derivatives was blocked because there were no more hydroxyl
protons at the ortho-position. However, enzyme-induced hydrolysis of weakly
fluorescent enzyme substrate derivatives respectively liberated either fluorescent
compounds. In addition, the coliform bacteria had also been detected because they
could grow in the presence of a β-gal substrate which was transformed by β-gal into a
fluorescent product that could readily be detected. Moreover, Wei et al. [23] successfully reported a series of ESIPT-based 2-(benzothiazol-2
0 -yl)-phenol fluorogenic
substrates for β-gal detection in 2017. They developed a novel efficient method for
the synthesis of important indoxyl glycoside substrates by using 1-acetylindol-3ones as intermediates and synthesized new precipitating fluorogenic substrates for
β-gal detection based on 2-(benzothiazol-2
0 -yl)-phenols and the ESIPT effect. And
they have also assessed the application of the fluorogenic substrates in the detection
of foodborne pathogenic bacteria.
Recently, although some fluorescent probes for β-gal have been developed, most
of the reported sensors were fabricated with traditional fluorophores, which suffered
from ACQ effect [17]. It causes the fluorescence in the aggregate state to be weaker
than with that in solution. Therefore, it is still highly demanded to explore β-gal
fluorescent probes, which could accumulate in living cells or tumor tissue imaging
without ACQ effect. In 2001, Tang’s group firstly found and reported the phenomenon of “aggregation-induced emission (AIE)” [24]. The compounds with AIE
effect are almost nonluminescent when they are dissolved in a good solvent but
emit intensely in a poor solvent. Meanwhile, the compounds with AIE effect have
significant advantages, such as bright luminescent in the aggregate state and large
Stokes shift [25–27]; thus, they have been greatly developed for detection of β-gal
[28, 29]. In 2015, Peng et al. [28] reported a salicylaldehyde azine derivative
SA-β-gal (11) for light-up detection of β-gal activity in living cells based on both
AIE and ESIPT effects. When the hydroxyl groups at the ortho-position on the
benzene ring of salicylaldehyde azine were substituted by β-galactopyranoside,
ESIPT process was blocked. Upon the addition of β-gal, the β-galactopyranoside
group on SA-β-gal was cleaved, and the restored hydroxyl group occurred in ESIPT
to regain the AIE characteristics, resulting in bright fluorescence. Contrary to
traditional β-gal fluorescent sensors, SA-β-gal could emit strongly in the aggregation
state, which can well avoid the ACQ phenomenon. The probe showed a large Stokes
shift, a high light-up ratio, and a high sensitivity (0.014 UmL
À1 ) toward β-gal.
Moreover, it was worth mentioning that the probe could also be well retrained in
living cells emitting strong fluorescence (Fig. 4).
In 2017, Jiang et al. [29] designed and synthesized a tetraphenylethylene-based
turn-on probe TPE-Gal (12) for β-gal detection with AIE effect in aqueous samples
and in living cells. TPE-Gal was designed to bear a positively charged pyridinium
pendant. And a substrate of β-galactosidase-D-galactose residue was conjugated to
the terminal of the pyridinium pendant. In the presence of β-gal, the D-galactose
residue was cleaved and resulted in a phenolate intermediate. Then the intermediate
192
A. Bi et al.
