Appendix A – Constituent level
*MATERIAL,NAME=ABQ_PLY_FABRIC_1_ABS5047_07
*DENSITY
1.8e-09
*USER MATERIAL, CONSTANTS=40
** Line 1: +1E, +2E, +12ν, 12G, −1E, −2E, −12ν
23200,21500,0.15,4980,23200,21500,0.15
** Line 2: +1X, −1X, +2X, −2X, S
322,220,250,180,40
** Line 3: +1fG, −1fG, +2fG, −2fG, 12α, max12d
9,9,9,9,0.41,1
** Line 4: 0~yσ, C, p
** Line 5:
1
*DEPVAR, DELETE=16
16
_______________________________________________________________________
ABS 5047-08
*MATERIAL,NAME=ABQ_PLY_FABRIC_ABS5047_08
*DENSITY
1.8e-09
*USER MATERIAL, CONSTANTS=40
** Line 1: +1E, +2E, +12?, 12G, -1E, -2E, -12ν
26100, 23100, 0.15, 5600,26100, 23100, 0.15
** Line 2: +1X, -1X, +2X, -2X, S
400,250,300,200,70
** Line 3: +1fG, -1fG, +2fG, -2fG, 12a, max12d
9,9,9,9,0.4,1
** Line 4: 0~ys, C, p
** Line 5:
1
*DEPVAR, DELETE=16
16
