FIGURE 4.69
Plots of the symbolic solutions of Example 4.15.
Example 4.16
The switch of the circuit of Figure 4.70 closes at t = 0, assuming that the circuit is initially relaxed, obtain analytical expressions of i(t), v l (t), v r (t), and v c (t) for t ≥ 0.
Create the script MATLAB fi le RLC_series that returns the analytical and symbolic
(Laplace) plots of i(t), v l (t), v r (t), and v c (t), over the range 0 ≤ t ≤ 10 s. Also verify KVL
given by
v(t) = v l (t) + v r (t) + v c (t) over the given time range
v (t ) = 10sin(3t )
R = 4 Ω
L = 2 H
C =1/20 F
switch closes at t = 0
i (t)
FIGURE 4.70
Circuit diagram of Example 4.16.
