where the designer is looking for cost-effective solutions. The MAX-7000 series of CPLDs are the most
widely used ones. MAX-9000 is similar to MAX-7000 except for its higher logic capacity. MAX-7000
series devices use advanced CMOS technology and (E
2 PROM)-based architecture and offer densities
from 32 to 512 macrocells with pin-to-pin propagation delays as small as 3.5 ns. MAX-7000 devices
support in-system programmability and are available with 5.0, 3.3 and 2.5 V core operating voltages.
There are three types of device in the MAX-7000 series. These include MAX-7000S, MAX-7000AE
and MAX-7000B. Three types are pin-to-pin compatible when used in the same package. Figure 9.38
shows the basic architecture of the MAX-7000 series of CPLDs.
AMD offers the Mach-1 to Mach-5 series of CPLDs. While Mach-1 and Mach-2 are configured
around 22V10 PALs, Mach-3 and Mach-4 use 34V16 PALs. Mach-5 is similar to the Mach-4
CPLD except that it offers higher speed performance. All Mach devices use E
2 PROM technology.
