Urban Air Quality: Meteorological Processes, Fig. 6
(a) Sketch of the regular
building array with indication of the source building. (b) Velocity vectors obtained from
wind tunnel experiments showing the vortex inside the canyon downwind of the source
building. (c) Velocity vectors obtained from CFD simulations. (d) Concentration profiles at different positions within the same street canyon with a sensitivity to the Schmidt
number value
