470
13 Experimental and Numerical Studies on Dynamic Behavior …
panels show prominent blast-resistant performance. The outstanding mechanical properties of UHPCC, especially the existence of steel fibers hinders the
development of cracks and improves the energy absorbing capacity of UHPCC.
(3) By comparing with the experimental incident and reflected instantaneous overpressures, the effectiveness of CONWEP method on predicting blast loadings,
especially the applicability on predicting the reflected overpressure of blast
wave induced by the one-end-detonated cylindrical charge with the scaled
distance of 0.5 ~ 1.0 m/kg
1/3 is validated. It is also indicated that the charge
shape and point of detonation affect the distributions of blast wave overpressure, and the corresponding influential degree increase with decreasing
the scaled distance, which leads to a decrease in prediction accuracy of the
post-blast behavior of panels.
(4) Karagozian & Case concrete (K&C) model parameters for describing the
strength surface, EOS, damage evolution, and the strain rate effect of UHPCC
were comprehensively calibrated by the existing basic mechanical properties
test data, which are fully validated by comparing with the present test data,
e.g. dynamic deflection-time histories and damage distributions.
References
AUTODYN. Century dynamics, theory manual[M]. 2005.
BARNETT S J, MILLARD S G, SCHLEYER G K, TYAS A. Briefing: Blast tests of fiber-reinforced
concrete panels[J]. Construction Materials, 2010, 163(3): 127–129.
CEB. CEB-FIP model code 1990[M]. Thomas Telford Ltd., London, 1993.
DRUCKER D C, PRAGER W. Soil mechanics and plastic analysis or limit design[J]. Quarterly of
Applied Mathematics, 1952, 10: 157–165.
ELLIS B D, DIPAOLO B P, MCDOWELL D L, ZHOU M. Experimental investigation and multiscale modeling of ultra-high-performance concrete panels subject to blast loading[J]. International
Journal of Impact Engineering, 2014, 69: 95–103.
FAN W, SHEN D, YANG T, SHAO X. Experimental and numerical study on low-velocity
lateral impact behaviors of RC, UHPFRC and UHPFRC-strengthened columns[J]. Engineering
Structures, 2019, 191: 509–525
FARNAM Y, MOHAMMADI S, SHEKARCHI M. Experimental and numerical investigations of
low velocity impact behavior of high-performance fiber-reinforced cement based composite[J].
International Journal of Impact Engineering, 2010, 37(2): 220–229.
FOGLAR M, HAJEK R, FLADR J, PACHMAN J, STOLLER J. Full-scale experimental testing
of the blast resistance of HPFRC and UHPFRC bridge decks[J]. Construction and Building
Materials, 2017, 144: 588–601.
FORQUIN P, GARY G, GATUINGT F. A testing technique for concrete under confinement at high
rates of strain[J]. International Journal of Impact Engineering, 2008, 35(6): 425–446.
GAO L. Research of high pressure equation of RPC[D]. Guangzhou: Guangzhou Univ., 2011. (in
Chinese)
GB/T 50081–2002. Standard for test method of mechanical properties on ordinary concrete[S].
Beijing: Standards Press of China, 2003.
GOVINDJEE S, KAY G J, SIMO J C. Anisotropic modeling and numerical simulation of brittle
damage in concrete[J]. International Journal for Numerical Methods in Engineering, 1995, 38(21):
3611–3633.
