5 Projectile Penetrations into Coarse Aggregated UHPCC Targets
Table 5.4
(continued)
Test
No.
V
0 (m/s) f
c (MPa) T
t (cm) V
f (%) da
(mm) V
cp (%) V
c (kg/m 3
) DOP
(mm)
Crater 1
Total
volume
(cm 3
)
Crater 2
Area 1
(cm 2
) Volume 1
(cm 3
)
dc
(mm) hc
(mm) Area 2
(cm 2
) Volume 2
(cm 3
)
α (°)
UHP-CAFRC 1-1
508
110.7
50
2
5–20
30
1126
98
237.4
387
410
174.5
54
239.0
501.7
54.1
1-2
508
50
2
5–20
30
1126
101
372.5
676
700
218.8
55
375.8
777.9
60.4
2-1
503
125.6
50
2
35–45
30
1126
21
135.8
126
126
138.8
21
151.2
128.7
73.2
2-2
515
50
2
35–45
30
1126
68
302.9
548
548
191
68
286.4
746.5
54.5
3-1
510
129.2
50
2
65–75
30
1126
59
197.8
214
214
161.5
59
204.8
475.6
53.8
3-2
517
50
2
65–75
30
1126
37
136.1
121
121
132
37
136.8
207.2
60.7
4-1
505
128.8
50
2
5–20
45
1700
145
212.0
299
341
161.5
54
204.8
435.3
51.6
4-2
507
50
2
5–20
45
1700
106
278.7
479
492
181.8
75
259.5
751.5
46.2
5-1
524
102.5
50
2
5–20
30
1126
106
253.4
453
468
179.3
56
252.2
546.7
54.0
5-2
511
50
2
5–20
30
1126
88
258.3
512
521
178.5
51
250.1
425.2
56.3
6-1-1 708
110.7
60
2
5–20
30
1126
171
549.3
995
1028
255.5
84
512.5
1591.0
53.9
6-1-2 710
60
2
5–20
30
1126
310
645.4
1169
1288
279.5
84
613.2
1886.6
56.5
6-2-1 722
110.7
60
2
5–20
30
1126
176
368.4
728
762
217.5
86
371.4
1202.8
48.2
6-2-2 720
60
2
5–20
30
1126
323
435.9
943
1080
242.8
95
462.8
1634.1
48.9
7-1
832
110.7
60
2
5–20
30
1126
185
244.5
409
450
179
82
251.5
798.4
43.1
7-2
846
60
2
5–20
30
1126
191
352.4
596
639
206.5
84
334.7
1066.2
47.2
HSC
1-1
510
61.8
60
0
5–20
40
1090
151
818.5
1843
1859
310.8
93
758.3
2557.6
56.9
1-2
516
60
0
5–20
40
1090
143
1204.7
2664
2686
376.5
85
1112.8
3378.9
64.2
