472
K. Bhavsar et al.
8 Conclusion
The robot is made of the two different cross sections: circular cross section arm and
square cross section arm. After doing the analysis, square cross section arm made of
stainless steel will be the best. After doing the analysis, the circular cross section arm
made of carbon epoxy will be the best. Also, the results of static structural analysis
conclude that the deformation of a robot of circular cross section arm made with
carbon epoxy > aramid > stainless steel at 5 KN. Also, the results of static structural
analysis conclude that the deformation of a robot of square cross section arm made
with aramid > carbon Epoxy > stainless steel at 5 KN. Stress is usually developed in
the joints which are in the permissible limit. A robot with a square cross section arm
should be used with any material as it gives better results than circular cross section
arm.
References
1. Hull D, Clyne TW (1996) An introduction to composite materials, 2nd edn. Cambridge
University Press, Cambridge, New York
2. Lee J et al (2016) Carbon/epoxy composite foot structure for biped robots. Compos Struct
140:344–350
3. Clothier KE, Shang Y (2010) A Geometric approach for robotic arm kinematics with hardware
design, electrical design, and implementation. J Robot 2010:1–10
4. Bugday M, Karali M (2019) Design optimization of an industrial robot arm to minimize
redundant weight. Eng Sci Technol Int J 22(1):346–352
5. Yeung KKH, Rao KP (2012) Mechanical properties of Kevlar-49 fibre reinforced thermoplastic
composites. Polym Polym Compos 20(5):411–424
6. Gautam R, Gedam A, Zade A, Mahawadiwar A (2017) Review on development of industrial
robotic arm. Int Res J Eng Technol 04(03):1752–1755
7. Karthikeyan P, Gobinath R, Ajith Kumar L, Xavier Jenish D (2017) Design and analysis of drive
shaft using kevlar/epoxy and glass/epoxy as a composite material. IOP Conf Ser Mater Sci Eng
197
8. Pachaiyappan S, Balraj MM, Sridhar T (2014) Design and analysis of an articulated robot arm
for various industrial applications. IOSR J Mech Civ Eng, 42–53
