30–80 μg of genomic DNA, and the limits of detection for 5hmC, 5fC, and 5caC
were reported to be 2–3 modifications per 10
5 cytidines [59].
More recent applications of HPLC-MS/MS for epigenetic marks of DNA have
employed two-dimensional HPLC (2D-LC) tandem mass spectrometry. A general
method for analysis of 5mC, 5hmC, 5fC, and 5caC was reported by Liu et al. [54]. In
this approach, DNA samples are enzymatically digested to nucleosides, followed by
ultrafiltration to remove proteins. A column switching nano-HPLC methodology
using two HPLC columns was used to allow for online sample cleanup prior to highresolution MS/MS analysis using a Q Exactive hybrid quadrupole-Orbitrap mass
spectrometer [54]. Using this methodology, 5mC, 5hmC, 5fC, and 5caC can be
quantified at low femtomole levels [54]. A similar methodology was reported by
Gackowski et al. [60]. 2D-LC allowed for isolation of peaks of interest (5hmC, 5fC,
and 5caC) as they eluted off the first HPLC column and directing them to a second
column, which was connected to a Waters Xevo TQ-S mass spectrometer. Using this
approach, a high level of sensitivity was achieved for 5hmC (LOD (limit of
detection), 3 fmol; LOQ (limit of quantitation), 10 fmol), 5fC (LOD, 0.3 fmol;
LOQ, 0.8 fmol), and 5caC (LOD, 0.05 fmol; LOQ, 0.13 fmol), and the amounts of
each were quantified in matched cancer and normal human colon tissue samples
[60]. By minimizing sample processing and analyte cleanup steps, 2D-LC methodologies significantly simplify sample analyses and minimize the cost, allowing for
high-throughput quantification of large numbers of samples.
Although the vast majority of mass spectrometry-based techniques do not allow
for mapping epigenetic marks along the genome, a recent report by Lin et al.
employed a mass spectrometry-based approach to determine local concentrations
of 5mC at specific genes [61]. Following endonuclease cleavage with BbvI, DNA
sequences of interest were captured by hybridization to complementary sequences
immobilized on streptavidin beads [61]. The captured DNA was heated in formic
acid to release 5mC as a free base, which was detected using an LTQ mass
spectrometer. Lin et al. used this method to probe methylation status of four
promoter regions: GSTP1, BCL2, ESR1, and HIC1 in DNA from clinical prostate
tissue samples digested with BbvI [61]. The capture methodology was able to
effectively distinguish cancer tissue from normal tissue based on the level of
promoter methylation of GSTP1, BCL2, ESR1, and HIC1 [61].
Biological samples from clinical studies are often precious, requiring method
minimization to reduce DNA input. Le et al. have developed an LC-MS/MS method
for the analyses of 5mC and 5hmC in 50 ng of DNA [62]. This effort employed an
Agilent 6,460 QQQ, an Agilent Eclipse C18 (2.1 Â 50 mm, 1.8 μm particle size)
column eluted at a flow rate of 100 μL/min. External calibration curves were
constructed using known concentrations of 5mC and 5hmC. This method was able
to quantify 0–10% 5mC and 0–2% 5hmC [62].
The recent discovery of N6MedA (Fig. 1) in mammalian embryonic stem cells
[29] was accomplished by offline HPLC separation of enzymatic DNA digests,
followed by HPLC-ESI-MS/MS analysis of N6MedA using a Waters UPLC coupled
to a TSQ Quantum Ultra triple-quadrupole mass spectrometer. Quantitation of the
N6MedA was performed with external calibration curves, and the identity of the
498
