Figure 10.7
Three schematics illustrating the concept of depressing the curved portion of the silastic
meniscus form overlaying the bacteria-rich media with the thin PDMS nanoconduit mold.
Eventually enough media and growth will occur to be fully covered by the overlay.
Figure 10.12
Microweaver bioreactor for biofabrication of meniscus implant and a prototype of a human
BNC meniscus implant. Source: BC Genesis.
Figure 12.6
Effects of the reaction time on the electrical conductivity of BNC/PAni.HCl composites.
