5 Numerical Models for Pebble-Bed Heat Transfer
radiation. The effect of emissivity was handled correctly in the local radiation model
without the uniform assumption. Since the computation cost of the local radiation
model in large-scale granular systems was huge and not applicable to the CFD-DEM
simulation, the particle-scale radiation model is developed to predict the radiation
flux in the DEM. It was shown that the effect of particle emissivity is a separable term
in the radiative heat transfer equation. The particle-scale radiation model provides
a good approximation of the local radiation model and enables the efficient prediction of radiative heat transfer in a densely packed bed. Also, the contact thermal
resistance with stagnant fluid is investigated by modeling the particle–particle and
the particle–wall conduction in a discrete particle simulation. The model predictions
of effective thermal conductivity are compared with various experimental data for
validation. The effect of the conductivity ratio and the void fraction is discussed.
