Chapter 6
Atomic Scale Kinetics of TSV Protrusion
Jinxin Liu, Zhiheng Huang, Paul Conway, and Yang Liu
6.1 Introduction
As discussed in Chap. 4, the microstructure of polycrystalline Cu is an important factor to fully understand the statistical behavior of TSV protrusion. Due to the random
nature of polycrystalline Cu, it is difficult to find a direct relationship between grain
structures and protrusions. Recently, statistical correlation between the microstructure and the protrusion was experimentally characterized by Spinella et al. [1] and
Messemaeker et al. [2]. Following Chap. 5, we provide a review on recent PFC modeling work [3–5] on TSV protrusion from the atomic scale in this chapter. The 2D
two-mode PFC model that is used to reproduce the protrusion behavior lists below,
