4A4
11
2
% /A /)5 //
Fig. 5.22. At what height h of the ledge will the intensity of light
at points located directly below be
(a) minimum;
(b) twice as low as /0 (the losses due to reflection are to be neglected).
5.111. A plane monochromatic light wave falls normally on an
opaque half-plane. A screen is located at a distance b = 100 cm
behind the half-plane. Making use of the Cornu spiral (Fig. 5.19), find:
(a) the ratio of intensities of the first maximum and the neighbouring minimum;
(b) the wavelength of light if the first two maxima are separated
by a distance Ax = 0.63 mm.
5.112. A plane light wave with wavelength 0.60 pm falls normally
on a long opaque strip 0.70 mm wide. Behind it a screen is placed
at a distance 100 cm. Using Fig. 5.19, find the ratio of intensities
of light in the middle of the diffraction pattern and at the edge of
the geometrical shadow.
5.113. A plane monochromatic light wave falls normally on a long
rectangular slit behind which a screen is positioned at a distance
b = 60 cm. First the width of the slit was adjusted so that in the
middle of the diffraction pattern the lowest minimum was observed.
After widening the slit by Ah = 0.70 mm, the next minimum was
obtained in the centre of the pattern. Find the wavelength of light.
5.114. A plane light wave with wavelength X = 0.65 p.m falls
normally on a large glass plate whose opposite side has a long rectangular recess 0.60 mm wide. Using Fig. 5.19,
find the depth h of the recess at which the
diffraction pattern on the screen 77 cm
away from the plate has the maximum
illuminance at its centre.
5.115. A plane light wave with wavelength X = 0.65 p.m falls normally on a
large glass plate whose opposite side has
a ledge and an opaque strip of width
a = 0.30 mm (Fig. 5.23). A screen is placed
at a distance b = 110 cm from the
plate. The height h of the ledge is such
that the intensity of light at point 2 of the
Fig. 5.23.
screen is the highest possible. Making use
of Fig. 5.19, find the ratio of intensities at points 1 and 2.
5.116. A plane monochromatic light wave of intensity Io falls
normally on an opaque screen with a long slit having a semicircular
p o
///////////////////
02
J /
/ // /// //
///
Fig. 5.24.
Fig. 5.25.
220
