4.3 Supplementary Problems
101
(a) In a first approach, a centered difference approximation should be written
for the inner nodes. Thus, a system of equations with the dimension dim. =
2 × (domain nodes − 2) is obtained. The values of u and φ at the right-hand boundary X = L should be replaced by appropriate boundary conditions for M Y and Q Z
based on backward difference schemes of O((X
2
).
(b) In a second approach, write a centered difference approximation which includes
in addition the node at X = L. Thus, a system of equations with the dimension
dim. = 2 × (domain nodes − 1) is obtained. Replace the values for u and φ at the
fictitious node based on appropriate boundary conditions for M Y and Q Z based on
centered difference schemes of O((X
2
).
