276
B. Gunawardana et al.
12.2 Materials and Methods
12.2.1 Materials
High purity chemicals such as PCP powder (ACS grade, 98%), 2,3,4,6tetrachlorophenol (2,3,4,6-TeCP, Supelco, 98%), 2,4,6-trichlorophenol (2,4,6-TCP,
Aldrich, 98%), 2,4-dichlorophenol (2,4-DCP, Aldrich, 99%), analytical standards of
PCP, phenol, chlorophenol isomers in methanol and nickel sulphate (NiSO 4 .6H 2 O,
>98%) were purchased from Sigma-Aldrich. Analytical grade solvents (ethyl acetate,
acetone), sulphuric acid (H 2 SO 4 ), and hydrochloric acid (HCl) were obtained from
Ajax Finechem. A stock solution (5000 mg/L) of individual CPs, i.e. PCP, 2,3,4,6TeCP, 2,4,6-TCP, and 2,4-DCP was prepared with the use of ethyl acetate as the
solvent. Deionized (DI) water with resistivity of 18.20 Mcm was prepared using a
Millipore-Q system and used for all the experiments. For the preparation of deoxygenated DI water (DW), the DI water was first degassed at 80 °C and 100 kPa for
one hour using a vacuum pump and then sparged with O 2 -free N 2 gas for half an
hour (dissolved oxygen level <0.2 mg/L).
The bimetal particles, i.e. nickel-coated ZVI (Ni/Fe) were synthesized as
explained by.Kim and Carraway (2000) The ZVI used for the preparation of Ni/Fe
particles was electrolytic iron powder (<100 mesh, North American Höganäs). Before
using for Ni/Fe synthesis, the ZVI particles were pre-treated with H 2 SO 4 (Liu et al.
2006). For the acid pre-treatment, as-received ZVI particles (500 g) were added to
1 N H 2 SO 4 solution (1.5 L), the mixture was agitated for 30 minutes at 100 rpm
and room temperature using a rotary shaker, and rinsed with DW. Post-rinsing of the
particles with DW, they were dried under continuous purging of N 2 gas for 4 hours
at 100 °C and then stored under N 2 gas environments until use for the synthesis
of Ni/Fe bimetals. The Ni/Fe particles were prepared using a reductive adsorption
method (Kim and Carraway 2000). A reaction solution with Ni was prepared by
adding a known volume of a Ni stock solution (2 ml of 2.4% Ni solution prepared
with NiSO 4 .6H 2 O and 10% H 2 SO 4 ) to 200 ml of DW water (pH of the prepared
solution = 1.60). Then, 100.0 (±0.01) g of acid pre-treated ZVI was added to the
solution (Kim and Carraway 2000). The mixture containing the Ni and ZVI was
placed on a rotary shaker and agitated for one hour at 100 rpm and followed by rinsing with DW and acetone, air-dried at room temperature, and stored under O 2 -free
N 2 gas to use for the experiments. The Ni
2+ solution was analysed for total Ni concentration pre- and post-exposure to acid-washed ZVI using the atomic absorption
spectroscopy (AAS). The AAS results showed 92% Ni removal from the solution
after Ni/Fe synthesis. Hence, based on the AAS analysis, the content of Ni deposited
on the Ni/Fe bimetallic particles was calculated to be 442 ppm (mg of Ni per kg of
Fe).
