2. Depending on the exact target and/or brain region of interest,
any other genetic background strain can be used. Expression of
a fluorescent protein in a target structure facilitates accurate
localization for in vivo electroporation.
3. Since current distribution along the pipette tip critically
depends on the exact geometry of the cone, shallow cone
angles are preferred for a more even distribution. This is
achieved more easily with a thin-walled glass capillary as compared to a thick-walled one.
4. Also, a wider tip opening will favor a more even distribution.
This, however, may come at the cost of more tissue damage so
that we found a tip opening of 3.5–4.5 μm to be a reasonable
compromise.
5. For simplification, a uniform flow of electric current, a constant
specific resistance ρ and no conductivity through the wall of the
glass are assumed in this description.
6. In theory, hole resistance could also be changed by the depth
parameter d. This, however, would either require the deposition of material or to carve out a shallow around a hole which
would make the fabrication process more complicated and with
longer time.
7. During tissue insertion, permanent low positive pressure
(10–20 mbar) is applied to the pipette to allow constant dye
perfusion of the tissue and to prevent tissue from extending
into the holes of the pipette.
