Abstract
There are many activities carried out by a company in installing a new or
revamped facility. Much of the initial work in executing a project is carried out
by the company’s development engineers in a series of “Front End Loading”
(FEL) stages to help insure the right facility is being built with the right economics. The discussion of project economics in the handbook chapter on economics
and planning meshes with the FEL efforts. Once the facility is well-defined, the
company will establish a team to execute the project. This chapter details the
steps in project execution starting at the FEL stage and continuing through
detailed design, guarantees, and into on-stream operation.
Keywords
Refinery • Project • Front-end loading • Guarantee • Specifications • Flow
diagram
Introduction to Project Execution
This chapter deals with the activities that are carried out by a refinery in installing
a new or revamped facility which has been approved by the mechanism defined
in the handbook chapter “▶ Petroleum Refinery Planning and Economics.” Much
788
D.S.J. Jones and S.A. Treese
