• The normalized pressure drop of 37 psi is somewhat high for most
reformers and may indicate some catalyst crushing or coking from age
or an incident. 37 psi is not particularly alarming. This value should be
trended over time.
• The steam carbon ratio at 4.53 is a little high for most PSA-type units, but
would be common in older units using solvent CO 2 cleanup. It could
probably be lowered.
15. These calculations can be built into a spreadsheet, including the trial-anderror, iterative solution to the reformer outlet composition and material
balance closure. This would save a significant amount of time and enable
more detailed operations evaluation to be completed more often.
