Graphene Oxide and Reduced Graphene Oxide as Nanofillers …
117
provides an effective method to develop freestanding, lightweight, and strong polyimide–GO composite materials with low dielectric constants and shows promise for
a wide range of applications.
Researchers have reported an in situ polymerization step that was combined
with chemical grafting modification for fabricating poly(vinyl alcohol)-grafted
GO/poly(vinyl alcohol) nanocomposites [81]. The poly(vinyl alcohol)-g-GO sheets
displayed great dispersion and compatibility with the poly(vinyl alcohol) matrix and
also created strong interfacial interactions with the poly(vinyl alcohol) chains of the
matrix [68].
2.3 Melt Processing
Melt processing is the most eco-friendly and economical method [53] and is appropriate for mass production of GO composites for industrial applications [82], but
the high viscosity of polymer melts and the high temperature used in this process
always leads to GO flocculation [83]. Besides, the high shear forces used in melt
compounding can often cause the breakage of the filler materials such as the
graphene-based nanosheets and CNTs [84]. However, these preparation methods
are less or more restricted in applications, they demonstrate their sole advantages to
fabricate polymer–GO composite materials [69].
In melt processing, no solvent is needed due to utilizing both high-temperature
melting and high-shear forces to mix the filler and matrix materials and combining
the graphene or modified graphene with the polymer matrix is done in the molten
state [36]. In this procedure, the polymer and graphene/GO/rGO are directly mixed
in a twin-screw extruder, and then the parameters of the extruder screw, such as the
screw speed, blending time, and temperature are regulated [68].
In general, most of the polymer–GO nanocomposites are prepared by using
polypropylene (PP), polyurethane, poly (ethylene terephthalate), poly (ether ketone),
Polystyrene (PS), styrene–ethylene/butylene–styrene triblock copolymers [45, 85–
87]. Melt blending is a promising method for the preparation of commercial
nanocomposite products because of its processing without using organic solvents
[68].
2.4 Pickering Emulsions
Pickering emulsion is the preparation of polymer nanocomposites via the selfassembly of nanoparticles at liquid–liquid interface [88]. It is a promising approach
for the design and preparation of well-defined nanostructured materials [89–91].
Self-assembly of the materials at the liquid–liquid interface is thermodynamically
promising because of the decrease in the interfacial energy of the system upon the
formation of a new interface between the liquid and particle phases instead of the
