Appendix A4: 235 U-Fueled ADS Core in Medium-Fast Spectrum
Table A4.7 List of core condition in all the cores shown in Fig. A4.3b (Ref. [1])
Case
# of fuel plates Rod
14 MeV neutrons
Repetition (Hz) Width (μs) Current (mA)
Case 3-D-1 2760
C1~S6 up 20
97
0.12
Table A4.8 List of core condition in all the cores shown in Fig. A4.3c (Ref. [1])
Case
# of fuel plates Rod (up) 14 MeV neutrons
Repetition (Hz) Width (μs) Current (mA)
Case 4-D-1
2520
C1~S6
20
85
0.08
Case 4-D-1T 2520
C1~S6
50
85
0.08
Case 4-D-2
2520
C1~S6
50
85
0.08
Case 4-D-3
2520
C1~S6
20
75
0.15
Case 4-D-4T 2520
C1~S6
50
85
0.15
Case 4-D-5
2520
C1~S6
50
85
0.15
Table A4.9 List of core condition in all the cores shown in Fig. A4.3d (Ref. [1])
Case
# of fuel plates Rod (up) 14 MeV neutrons
Repetition (Hz) Width (μs) Current (mA)
Case 5-D-1
2280
C1~S6
20
97
0.08
Case 5-D-2
2280
C1~S6
100
97
0.08
Case 5-D-3T 2280
C1~S6
20
97
0.08
Case 5-D-3
2280
C1~S6
20
97
0.08
Case 5-D-4
2280
C1~S6
50
97
0.08
Table A4.10 List of core condition in all the cores shown in Fig. A4.3e (Ref. [1])
Case
# of fuel plates Rod (up) 14 MeV neutrons
Repetition (Hz) Width (μs) Current (mA)
Case 6-D-1T 2040
C1~S6
20
93
0.10
Case 6-D-2
2040
C1~S6
100
97
0.10
Case 6-D-3
2040
C1~S6
50
97
0.08
Case 6-D-4T 2040
C1~S6
50
97
0.08
Case 6-D-5
2040
C1~S6
500
20
0.20
