2.4 Methods and Materials
49
2.4.6 Structure Determination and Refinement
Data collection, integration, scaling, and empirical absorption correction were carried
out in the Rigaku CrystalClear-2.054 program package. The structure was solved
in 0.82Å resolution by direct method using the software of SIR201155 and well
refined by Full-Matrix-Least-Squares against F2 by SHELXTL97 [55]. The nonhydrogen atoms were anisotropically refined and hydrogen atoms were placed at
idealized positions and refined using the riding model. The absolute configuration
was determined using the method of Flack [56]. The statistics of data collection and
final refinement were shown in Table 2.4.
2.4.7 Computational Studies
2.4.7.1 Methods for Computational Studies
Simulation settings: All simulations were carried out using the Gromacs 4.5.4 [57].
Our recently developed residue-specific force field [58, 59] RSFF2 [60] was used to
treat each peptide, except for the tether, which was described using the generalized
Amber force field (GAFF) [60, 61] with the restrained electrostatic potential (RESP)
[62] charges. Each starting structure was initially constructed using the HyperChem
software, and solvated in a truncated octahedron box (30 Å in length) with 647709 TIP3P water molecules (depending on the peptides). Energy minimization was
carried out using steepest descent method. Then, the initial periodic box volume was
equilibrated using a 3 ns MD simulation in an NPT ensemble near 300 K and 1 atm.
Subsequently, the initial structures for REMD were obtained at regular intervals
from a 30 ns NVT MD trajectory at 600 K. For each REMD simulation, 24 replicas
were used with temperature range from 300 K to 600 K. By frequently exchanging
the replicas of different temperatures, REMD can speed up the barrier crossing and
achieve higher efficiency in conformational sampling [63].
The electrostatics were treated using the particle-mesh Ewald (PME) method [64]
with a real-space cutoff of 0.9 nm and van der Waals interaction cutoff at 0.9 nm
with the long-range dispersion correction for energy and pressure in all simulations.
A velocity rescaling thermostat [65] with τ T = 0.2 ps and a Berendsen barostat [66]
with τ P = 0.5 ps were used to maintain constant temperature and constant pressure
(for NPT simulations), respectively. All bonds involving hydrogen were constrained
using LINCS [67], and a time step of 2 fs was used. At the same time, the mass of water
oxygen atom was reduced from 16 to 2 amu to increase the sampling efficiency [68]
without altering the thermodynamics equilibrium properties. 24 replicas of the system
were simulated simultaneously at temperatures from 300 to 600 K. The intermediate
temperatures were chosen following a recent study [69] to obtain uniform exchange
rate, and exchanges were attempted between neighboring replicas every 1.0 ps. The
