7. DNA purification kit (see Note 4).
8. Genomic cleavage assay kit (see Note 5).
9. Forward and Reverse primers for the PCR step in genomic
cleavage assay: GACGTAAACGGCCACAAGTT (Forward).
GCGGATCTTGAAGTTCACCT (Reverse).
10. Gel electrophoresis setup.
11. Agarose.
12. 10Â Tris/Acetate/EDTA (TAE) buffer: 400 mM Tris–acetate,
10 mM EDTA, pH 8.0 (see Note 6).
13. 10 mg/mL Ethidium bromide (Bio-Rad) (see Note 7).
14. 1 kb DNA ladder.
3 Methods
3.1 Electrospun Fiber
Scaffold Preparation
1. Prepare electrospun fiber scaffolds by electrospinning [14, 17]
(see Note 8).
2. Melt 1 g of PCL (40 kDa) at 60
C for 30 min to form a PCL
block in a mold (see Note 9). After this PCL block is formed,
trim the block down to 10 mm by 5 mm by 10 mm before
using a cryostat to section this block into small strips of PCL
films of 20 μm thickness.
3. Dissolve PCL (80 kDa) in TFE (14% W/V) overnight.
4. Vortex the solution until homogenous.
5. Before electrospinning, adhere the small strips of PCL films
(40 kDa) with 20 μm thickness onto glass coverslips (diameter
ϕ 18 mm) to create a 10 mm  10 mm area. Place these PCL
films onto the coverslips to form a square configuration before
melting them on a hotplate, at 50
C for 15 s. Remove coverslips from hotplate once these films turn transparent.
6. Fix 8 coverslips on a rotating collector (ϕ ¼ 15 cm) with carbon
tapes.
7. Electrospin the PCL fibers onto the coverslips that are fixed on
a rotating collector (2400 rpm). Apply a flow rate of 1.0 mL/
h and voltages of +8 kV and À4 kV to the needle tip and
rotating collector, respectively. Fix the spinneret-to-collector
distance at 21 cm. Allow electrospinning to occur for 6 min
30 s (100 μL of 14% W/V PCL solution electrospun) before
removing the coverslips off the rotating collector.
8. Secure the electrospun PCL fibers onto the coverslips with
silicone glue. Using a fine paintbrush, apply a small amount
of silicone glue along the parameter of the square configuration
formed by small strips of PCL films (refer to step 5). Allow
186
Wai Hon Chooi et al.
